For industrial use, order the O-ring by the Parker compound number followed by the size number.Ĥ. Find the recommended O-ring size and gland dimensions in the appropriate design table in Static O-Ring Sealing or Dynamic O-Ring Sealing, Sections IV and V, respectively.ģ. (b) If the compound specification is known, refer to Table 8-2, Table 8-3 or Table 8-4 in Section VIII as applicable.Ģ. (a) If the fluid medium or its specification is known, refer to the Fluid Compatibility Tables in Section VII or to the various material or other specifications listed in Section VIII. Determine the gland design for best sealing results.
#Seal design software laserdrw manual#
When access to these tools are note available, manual calculations can be performed using the following guidelines.ġ. To use these tools, visit and select the Solutions tab. Parker’s calculators not only address standard O-ring sizes, but allow users to custom design O-ring glands and seals specifically for their application. Parker recommends utilizing our design tools (Mobile inPHorm and the O-Ring Selector)design software to guide the user through the design and selection of an O-ring and corresponding seal gland.
O-Ring Design Procedure using Mobile inPHorm. Mobile inPHorm - Parker's Design Tool & O-Ring Calculator
